Name: ▷ Buy New New Arrival 220v/50hz/1ph MPV280 Multi-purpose Mini Hobby Lathe Machine In Stock () - Available at MachineryGenie.com
SKU: 4000926625339
Price: 3429.00 JPY
Availability: InStock

Description

Attention please!!!

Please kindly read the following tips before purchasing.

1. The transaction of large machinery cannot be completed on AliExpress.

2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port.

3. If any problem please feel free to contact with us.

Whatsapp 86 18656680921 Email [email protected]

D300V Mini Manual Desktop Lath in Chinese Factory

Features:
1. Precision ground and hardened bed ways.
2. The spindle is supported with precision roller bearings.
3. Headstock gears are made of high quality steel, ground and hardened.
4. Easy operating speed change levers.
5. Easy operating gear box has various feeds and thread cutting function.
6. With or without cabinet according to requirement.

Specifications	D300V
Max. swing over bed	φ300mm
Distance between centers	700mm
Max. swing over cross slide	190mm
Width of bed	182mm
Spindle bore	38mm
Taper of spindle bore	MT5
Spindle speed range 6 steps	80-2000rpm
Spindle speed range(variable speed)	150 300 600 500 1000 2000rpm
Metric threads can be cut	0.2-3.5mm
Inch threads can be cut	8-48TPI
Top slide travel	70mm
Cross slide travel	170mm
Tailstock quill travel	70mm
Taper of tailstock quill	MT3
Motor power	1500W
NW/GW	260/280KG
Packing size(LXWXH)	1500X720X680mm
