GUTE Machinery GWH-32E Steel Bar Spiral Bender

Contact this seller for accurate pricing

In stock

Feature:

Bending capacity up to 32mm

3 Phase Motor provides excellent power

Excellent performance

Less noise and vibration

  Chat Now
SKU: GUTE-GWH-32E Categories: , Brand:

Description

Product Details


• GWH-32E adopts the fully enclosed GEAR BOX separated from the working disk for no distortions even under the condition of heavy loads and no oil leaking while lifting the machine.

• GEARS, GEAR SHAFT, GEAR BOX and BENDING WHEELS made of high-quality alloyed steel with proper heat treatment (quenching/ tempering) and 2 mm thick external case to ensure high performances also under heavy loads and long working life.

• FLY WHEEL and side bolts to ensure accuracy of the bending diameter also after stopping and restarting.

• Adjustable bending angle from 10° to 360°.


MOTOR TYPE

GWH-32E

• MOTOR TYPE: Y100L2-4  DUST PROOF

• MOTOR POWER: 3,0 kw-4P

* Motors has 1 year warranty.

* VOLTAGE OPTIONS: any voltage from 220 to 440 / 220-380 (switchable)


* FREQUENCY OPTIONS: 50Hz / 60Hz

STEEL BAR SPIRAL   BENDER GWH-32E

Bending   Capacity

6-32   mm (ob ≤450N/mm2)

6-28   mm (ob ≤650N/mm2)

Operation

Automatic

Type   of Motor

Y100L2-4

Motor   Power

3   KW-4P

Motor   Rotation Speed

1430   R/min

BENDING   WHEELS SPEED

15   R/min

Speed   of Working Disk

9   R/min

Noise   Value (1m away)

≤75dB(A)

Weight

340   Kg.

Dimension

900*800*950   mm

Certification

ISO   9001:2008
