GUTE Machinery GWH-32E Steel Bar Spiral Bender
Feature:
Bending capacity up to 32mm
3 Phase Motor provides excellent power
Excellent performance
Less noise and vibration
Description
Product Details
• GWH-32E adopts the fully enclosed GEAR BOX separated from the working disk for no distortions even under the condition of heavy loads and no oil leaking while lifting the machine.
• GEARS, GEAR SHAFT, GEAR BOX and BENDING WHEELS made of high-quality alloyed steel with proper heat treatment (quenching/ tempering) and 2 mm thick external case to ensure high performances also under heavy loads and long working life.
• FLY WHEEL and side bolts to ensure accuracy of the bending diameter also after stopping and restarting.
• Adjustable bending angle from 10° to 360°.
MOTOR TYPE
GWH-32E
• MOTOR TYPE: Y100L2-4 DUST PROOF
• MOTOR POWER: 3,0 kw-4P
* Motors has 1 year warranty.
* VOLTAGE OPTIONS: any voltage from 220 to 440 / 220-380 (switchable)
* FREQUENCY OPTIONS: 50Hz / 60Hz
|
STEEL BAR SPIRAL BENDER GWH-32E |
||
|
Bending Capacity |
6-32 mm (ob ≤450N/mm2) |
6-28 mm (ob ≤650N/mm2) |
|
Operation |
Automatic |
|
|
Type of Motor |
Y100L2-4 |
|
|
Motor Power |
3 KW-4P |
|
|
Motor Rotation Speed |
1430 R/min |
|
|
BENDING WHEELS SPEED |
15 R/min |
|
|
Speed of Working Disk |
9 R/min |
|
|
Noise Value (1m away) |
≤75dB(A) |
|
|
Weight |
340 Kg. |
|
|
Dimension |
900*800*950 mm |
|
|
Certification |
ISO 9001:2008 |
|
