Name: ▷ Buy New CJM280 500mm Mini Desktop Lathe Machine for Home Use () - Available at MachineryGenie.com
SKU: 1005001469265188
Price: 3477.45 USD
Availability: InStock

Description

Attention please!!!

Please kindly read the following tips before purchasing.

1. The transaction of large machinery cannot be completed on AliExpress.

2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port.

3. If any problem please feel free to contact with us.

Whatsapp 86 18656680921 Email [email protected]

CJM280 750mm Mini Desktop Lathe Machine for Home Use

Features:
1. Precision ground and hardened bed ways.
2. The spindle is supported with precision roller bearings.
3. Headstock gears are made of high quality steel, ground and hardened.
4. Easy operating speed change levers.
5. Spindle speed range 80-1600rpm.
6. Easy operating gear box has various feeds and thread cutting function.
7. With or without cabinet according to requirement.

Model	CJM250	CJM280
Swing over bed	250mm	280 mm
Center distance	500mm	500 mm	750mm
Swing over carriage	150mm	160 mm
Spindle bore	26mm	38 mm
Spindle taper	MT4	MT.5#
Swing over toolpost		140 mm
Longitudinal travel over toolpost	60mm	75 mm
Metric thread available	9	18
Metric thread range	0.25-2.5mm	0.20~3.5 mm
Inch thread available	15	34
Inch thread range	12-96TPI	41/2~48 1/n″
Longitudinal feed on spindle toolpost	0.025-0.25mm/r	0.08~0.56 mm/r
Cross feed on spindle toolpost	0.0125-0.125mm/r	0.04~0.28 mm/r
Tailstock sleeve travel	60mm	60 mm
Tailstock sleeve taper	MT.3	MT.3#
Spindle speed step	12	8
Spindle speed range	80-1600r/min	90~1800 r/mim
Motor	750W 380V 50HZ (220V 50HZ)	750W 380V 50HZ (220V 50HZ)
Packing size	1160640580mm	1450×650×1200mm	1200×650×1200mm
