Name: ▷ Buy New CJM250 Mini Metal Lathe Machine Price with Auto Feeding () - Available at MachineryGenie.com
SKU: 4000916922433
Price: 2472.84 JPY
Availability: InStock

Description

Attention please!!!

Please kindly read the following tips before purchasing.

1. The transaction of large machinery cannot be completed on AliExpress.

2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port.

3. If any problem please feel free to contact with us.

Whatsapp 86 18656680921 Email [email protected]

CJM320A 750mm Stock Sale Bench Lathe Machine for Hobby Use

Features:
1. Precision ground and hardened bed ways.
2. The spindle is supported with precision roller bearings.
3. Headstock gears are made of high quality steel, ground and hardened.
4. Easy operating speed change levers.
5. Spindle speed range 60-1600rpm.
6. Two different lengths of bed are available.
7. With or without cabinet according to requirement.

Specification	CJM320A-600/750mm
Max. swing over bed	330mm
Max. swing over cross slide	220mm
Max. length of work piece	600mm/750mm
Width of bed	160mm
Spindle taper and bore	MT5/38mm
Max.lateral stroke over tool post	160mm
Metric pitches range	0.5-4 mm
Inch pitches range	9-40 T.P.I
Longitudinal-feed range	0.135-1.80mm/r
Max. travel of tailstock sleeve	70 mm
Tailstock sleeve taper	MT3
Spindle speeds range	60-1650r/min(50hz)
Motor	1.1Kw
NW/GW (without stand)	280/300kg 320/340Kg
Packing size (without stand)	1330x760x720/1550x760x720mm
Packing size	1330x760x1370/1550x760x1370mm
