Name: ▷ Buy New Small Size Manual Metal Lathe CJM280 Hobby Home Bench Lathe Machine With Low Price () - Available at MachineryGenie.com
SKU: 1005006110786600
Price: 2160.00 USD
Availability: InStock

Description

Attention please!!!

Please kindly read the following tips before purchasing.

1. The transaction of large machinery cannot be completed on AliExpress.

2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port.

3. If any problem please feel free to contact with us.

Whatsapp 86 18656680921 Email [email protected]

Main Features:

1. Precision ground and hardened bed ways.

2. The spindle is supported with precision roller bearings.

3. Headstock gears are made of high quality steel, ground and hardened.

4. Easy operating speed change levers.

5. Easy operating gear box has various feeds and thread cutting function.

6. With or without cabinet according to requirement.

Specifications	D280V
Max. swing over bed	φ280mm
Distance between centers	700mm
Max. swing over cross slide	125mm
Width of bed	180mm
Spindle bore	26mm
Taper of spindle bore	MT4
Spindle speed range 6 steps	50-2500rpm
Spindle speed range(variable speed)	150 300 600 500 1000 2000rpm
Metric threads can be cut	0.2-4mm
Inch threads can be cut	8-56TPI
Top slide travel	70mm
Cross slide travel	140mm
Tailstock quill travel	70mm
Taper of tailstock quill	MT2
Motor power	1500W
NW/GW	200/230KG
Packing size(LXWXH)	1450X700X680mm

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2: Can we visit your factory before order?

A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3: Do you have a stock?

A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4: What’s the MOQ?

A4: One set only.

Q5: How about your quality?

A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6: Do you have professional engineers?

A6: Yes, we have professional engineers and designers. We can provide OEM services.

Q7: Can you provide customized machines?

A7: Yes, we can design and manufacture according to your specific requirements.
