GUTE Machinery GW50C Automatic Steel Bar Bending Machine

Contact this seller for accurate pricing

In stock

Feature:

Bending capacity up to 42mm

3 Phase Motor provides excellent power

Excellent performance

Less noise and vibration

  Chat Now
SKU: GUTE-GW50C Categories: , Brand:

Description

Product Details


1.GW50C series adopts the fully enclosed gear box separated from the working disk for no distortions even under the condition of heavy loads and no oil leaking while lifting the machine.

2.Gears,gear shafts,working disk,stop gauge,saddles,pile heads and pile head bushes made of high-quality alloyed steel with proper heat treatment(quenching/tempering/high frequency)and 3mm thick external case to ensure high performances also under heavy loads and long working life.

3.Dust proof brake motor and two limit switch to ensure the accuracy of the bending angle also after stopping and restarting.

4.Insert pin type disk and movable saddles for a precise adjusting of the bending angle.

5.CE certification


MOTOR TYPES

GW40AG-4(automatic)

•MOTOR TYPE: Y100L2-4 DUST PROOF (Brake motor)

• MOTOR POWER: 3,0 kw-4P

GW40AG-1 (manual)

• MOTOR TYPE: Y100L2-4  DUST PROOF

• MOTOR POWER: 3,0 kw-4P

*Both kinds of motor automatic and manual have 1 year warranty.

* VOLTAGE OPTIONS: any voltage from 220 to 440 / 220-380 (switchable)

* FREQUENCY OPTIONS: 50Hz / 60Hz

STEEL BAR BENDER GW50C AUTOMATIC / MANUAL

Bending Capacity

6-42mm (ob ≤450N/mm2)

6-40 mm (ob ≤650N/mm2)

Operation

Automatic

Manual

Type of Motor

YEJ 112M-4 (Brake motor)

Y 112M-4

Motor Power

4 KW-4P

4 KW-4P

Motor Rotation Speed

1440 R/min

1440 R/min

Speed of Working Disk

9 R/min

9 R/min

Noise Value (1m away)

≤75dB(A)

≤75dB(A)

Weight

476 Kg.

465Kg.

Dimension

1000*800*900 mm

1000*800*900 mm

Certification

ISO 9001:2008









Hot Tags: automatic steel bar bending machine, manufacturers, suppliers, price
