Quality Turkish L Shaped Architrave Gluing Machine Door Jamb Frame Moulder with Glue System
$20,250.00
- AUD: A$31,447.64
- GBP: £16,877.97
- EUR: €19,654.65
- JPY: ¥3,183,462
- CNY: ¥147,758.17
The Quality Turkish L-shaped architrave gluing machine features a built-in glue system and is designed for precise molding of door jamb frames. It ensures strong, accurate gluing and high-quality results for architrave production.
Description
Product descriptions from the supplier
Product Overview
L SHAPED ARCHITRAVE GLUING MACHINE
Machine for gluing L-shaped jamb is using in production the door, door casing and door frame. This machine is intended to bond two
MDF panels certain size (certain width and thickness)at 90 ˚ with subsequent formation of a jamb (sill) in the form “L”-profile.
Also, the machine performs all the operations necessary to make the final appearance of the billet. All processes on the machine
are fully automated.
Capacity: 250 – 300 Pieces Per Hour
VISIT OUR WEBSITE
www.boygatech.com
+90 541 794 40 09 (Whatsapp Available)
FEATURES AT A GLANCE
Features Of Machine Tool:
1. Automatic Feeding Of Profiles
2. Gluing “L” Shaped Sill
3. Right-Left Milling
4. Grooving
5. Joint (juncture) Opening
6. Chamfering
Thickness of main workpiece 8-30 mm
Thickness of side workpiece 3-6 mm
Width of main workpiece 60-120 mm
Width of side workpiece 10-80 mm
Working Speed 16 m/min
Tutkal Kazanı Kapasitesi 3 kg
Resistance Power of glue pot 3650 watt
Total Motor Power 8,67 kw
Output for Sawdust 2 piece / Ø115 mm – Ø80 mm
Total Electric Power 11,5 kw
Air pressure 6 bar
Mains Voltage 380 V, 50-60 Hz
Current Intensity 45 A
Working Dimensions (L/W/H) 5500 x 1400 x 1200 mm
Shipping Dimensions (L/W/H) 3500 x 1200 x 1700 mm
Weight ≈ 950 Kg
Thickness of side workpiece 3-6 mm
Width of main workpiece 60-120 mm
Width of side workpiece 10-80 mm
Working Speed 16 m/min
Tutkal Kazanı Kapasitesi 3 kg
Resistance Power of glue pot 3650 watt
Total Motor Power 8,67 kw
Output for Sawdust 2 piece / Ø115 mm – Ø80 mm
Total Electric Power 11,5 kw
Air pressure 6 bar
Mains Voltage 380 V, 50-60 Hz
Current Intensity 45 A
Working Dimensions (L/W/H) 5500 x 1400 x 1200 mm
Shipping Dimensions (L/W/H) 3500 x 1200 x 1700 mm
Weight ≈ 950 Kg
