Portable Boring Machine

LINEBORTECH BD60 MODEL

PROCESSING DIAMETERS
(Ø52 mm: up to Ø700 mm)

LINEBORTECH has been manufactured to work in the renovation and repair services of various heavy industrial machines.

The first model of the LINEBORTECH machine in different concept is LINEBORTECH BD60 is generally manufactured for Ø 52 mm Ø 700 mm for chip lifting, in-hole welding, and turning operations.

Extra equipment is added for work up to Ø 800mm. The machines ergonomic design, easy handling, and light weight are the most outstanding features.

LINEBORTECH We have different features
* Oil-free / silent, system driven speed/torque belt transfer
* Worm gear spindle adjustment and quick traverse button
* 230mm continuous machining distance
* Constant torque output at all set speeds with encoder capacity of the main motor
* Centering set a punch
* Telescopic welding torch
* Control needle. excluding. Weight 15 kg.

Diameter details
Perforated Machining: Ø52mm – 700mm
External Processing: With Optional Attachments
Perforated Welding: Ø60mm – 700mm
Head Turn: With External Kit

TECHNICAL DATA
BD60 Different Product Features
Motorized Gearbox
Teeth 55 Hrc Hardened And Grinded.
6000 Hours Usage Guarantee
HOLE PROCESSING CAPACITY
In-hole turning
Up to 600mm at 62mm
Intra-Hole Welding
From 80mm up to 450mm

ELECTRICAL ENGINE EQUIPMENT
Main Bar Rotation Motor
Ac 230V Ac Servo Motor
Min 0,20 Rpm Max. 225 RPM
Main Bara Forward Backward Motor
24vdc 90w Servo Motor
Moving Speed Min 0,05 Mm / Dk Max 95 Mm / Dk
Strok 250 Mm

Standard Hardware

ELECTRONIC CONTROL PANEL
Operating Voltage: Ac 230v 50 / 60Hz -10 amp.
Master On-Off Switch
Emergency Button
Right / Left Rotation Switch
Speed Tuning Button 10 Turn
Forward / Backward Motion Key
Speed Tuning Button 10 Turn
Fast Motion Button
Reset button
Control Screen

STANDARD EQUIPMENT LIST
1 piece 1700 Mm Bar shaft
1 Unit with Electronic Control Panel
1 Portable Boring Machine
1 Carrying Vehicle
4 Main Beds
12 Short Legs 30x30x60
2 Unit Centers
1 Unit Sag Processing Kateri
1 Unit Left Handle Cart
1 piece Diamond Set 10 pieces
1 Set of Aylan Key Set (2,5-4-5-12)
1 Screwdriver Star Head
1 Number 10 Phillips Screwdriver
2 pieces 20/22 Fork Switch

If you want more information about the portable line boring machine feels free to contact us.
