Name: ▷ Buy New KINGISO China High Quality Automatic Woodworking Cabinet Hinge Boring Machine With Double Heads For Furniture Production Line () - Available at MachineryGenie.com
SKU: 1005006844412798
Price: 2.00 USD
Availability: InStock

Description

My friend, welcome to our store, if you need other models of this product, please contact me, I will send the product link for you to buy! And welcome to add my WHATSAPP (+8618175124931) This product does not include free shipping. Please check the shipping cost with the customer service staff when purchasing. Thank you.

Hot sale products

Three Row Drilling Machine

Sanding Machine

CNC Router

Edge Banding Machine

Application:

Suitable for all kinds of MDF, particleboard, plywood, PVC board, plexiglass, and solid wood plate drilling;

Multi axis woodworking drilling machine can fine to help you build furniture, wood, etc., you can save your manpower and material resources, so that you put more down.

Features:

1.The drilling covers a large scope,and all the bits can be installed quickly and conveniently;

2.The drilling depth and distance are controlled photoelectric switch(optional)and linear guide, so it can find out the location quickly and accurately;

3.The adoption of imported drillers improves durability

4.Selection of high quality steel machine parts,and it is never deformation by high-strenth heat treatment;

5.Equipped with digital calculator to measure size which enhances the work efficiency.

Advantage:

1.This machine tool has the advantages of high efficiency, good rigidity, high precision, low noise, wide speed range, high speed operation, novel appearance, convenient maintenance and so on.

2.One-button control panel, operate easily.

Technical Parameter:

Max.drill dia	35mm
Max.boring depth	60mm
Max dimensions of pieces to be drilled	2400x640x80mm
Max.processing length of vertical head	1200mm
Min.processing length of horizontal head	900mm
Numbers of spindle	21
Spindle speed	2840r/min
Installed power	1.5kw
Air pressure	6-8kg/cm²
Suitable voltage	380V 50HZ
Min center distance between spindles	32mm
Gas consumption for drilling ten panels per min	11L/min
Overall size	240011501500mmNet weight 450kg
Net weight	450kg

Detailed Images

Finshed Products

Packing&Service

1.Delivery:
We can guarantee delivery on time.
We also can sign on-time delivery contracts. If we can’t deliver on time, we will give the product a corresponding discount.
2.Package:
We will take care of your machinery packages well like picture show.
Our workers will make sure your machine clean before package.
We will add stretchy film for the whole machine and spare parts for delicate protection.
We will make export standard strong Wooden box case package as your request.
3.Guarantee:
The machine is guaranteed for 12 months .Within 12 months under normal using and maintenance, if the machine has something problem ,you will get spare part for free . More than 12 months,you will get the cost price for accessories. You will also get technical support and service all the time.
4.Technical support:
Technical support by Phone, Email, Wechat, WhatsApp and Skype, 24 hours online.
We provide English version manual and Operational video.
Engineer available to service machinery overseas.
5. After sales services:
Our machine is installed and tested well before delivery. You can operate the machine immediately after receiving machine.
If you don’t know how to use the machine, we will offer you free training until you can use machine freely. And If there is still have any question, please contact us by Email, Skype, Wechat, WhatsApp, Phone and Trade Manager online service at any time.
