Name: ▷ Buy New Hwashi multi-point spot gantry welding machine , Concrete Reinforcement Steel Mesh Welding Machine () - Available at MachineryGenie.com
SKU: 1005005736396405
Price: 42572.50 USD
Availability: InStock

Description

Product Description

We are the professional multi-head automatic welding machine Chinese manufacturer, our company supply wire mesh multi-head automatic welding machine optimal price and sell the steel fence multi-head automatic welding machine, if you want to know wire mesh multi-head automatic welding machine performance and wire mesh multi-head automatic welding machine optimal price in China, you can contact us to sell the steel fence multi-head automatic welding machine. Do you seek a professional multi-head automatic welding machine Chinese manufacturer?

Product Application

Steel fence wire mesh multi-head automatic welding machine quality is H-type wire mesh multi-head automatic welding machine performance. It adopts six electrodes and equips with automatic feeding system. The wire will be dropped to the fixture automatically to achieve full automatic loading. After that it will automatically execute the feeding and welding. Its one-way and double-layer feeding device can move forward and back automatically to finish the welding and the welding distance can be set at random .It is suitable for the batch production of wire mesh with multiple-points welding.
The welding manner is one-way double-layer automatic stepping feeding with 6 welding heads. The effective welding width is 780mm while the effective welding length is 1000mm.
This machine is composed of gantry type support, welding transformer, pneumatic drive device, upper and lower electrodes,electrical control system, cooling system, and PLC operation control system.

Features of steel fence wire mesh multi-head automatic welding machine

1.The number of welding heads is depends on the welding width of the mesh. Different welding head can be set different welding programs and current respectively.
2.X and Y axis automatic wire filling system for automatic loading of the wires (within 1200mm).
3.This machine can help to achieve full automatic welding process basically. It helps to increase the production rate and save labor cost dramatically.

Technical Details

No.	Item	Data
1	Input Voltage	380V two-phase
2	Input Current	260A
3	Output Voltage	AC7.5V
4	Max Short Circuit Current	26000A
5	Welding Models	30 types
6	Welding Positions	5000 point
7	Different Welding Current	8 types
8	Welding Effective Width	1200mm(Can be customized)
9	Welding Effective Length	1000mm (Can be customized)
10	Feeder Moving Speed	100mm/sec－800mm/sec
11	Feeder Moving Force	Servo Motor
12	Upper Welding Cylinder	10(￠100x80mm)
13	Lower Welding Cylinder	2(￠125X50mm)
14	Fixture Feeder	2

1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price. 2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier. 3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery. 4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant. 5. Quick Delivery: Our company provides just-in-time delivery. 6. Prompt Response to Customers: Your satisfaction is the goal we pursue.

Story About HWASHI

Guangdong Hwashi Technology Inc. was established in 2001. The headquarter is located in Hwashi industrial park in Huizhou. Hwashi is a high-tech enterprise specialized in developing, manufacturing and selling of resistance welding machine, automatic welding machine and an industrial robot.

In the past 20 years, Hwashi has obtained more than 50 patents for invention patents, utility model patents, design patents, and software Copyrights. It is the drafting unit of several national standards and industry standards. Hwashi has been awarded “China famous brand”, “Guangdong famous brand”, “China quality credit enterprise”, “world outstanding Chinese businessman association member unit”, “Guangdong province science and technology innovation quality management advanced unit”, “Guangdong province academician expert enterprise workstation” and many other honorary titles.

For 20 years, Hwashi keeps innovating and follow up with the latest technology in the world. Invest heavily in product development and innovation every year. In cooperation with key universities and national key laboratories and engineering technology centers in new materials and processes, the “medium frequency inverter” technology was first introduced into resistance welding equipment. Help to realize the “unmanned, intelligent” factory, the practice we have been striving for is to create efficient, energy saving, safe and environmentally friendly production environment for customers.

With the trend of intelligent manufacturing in the world, Hwashi has set up a large-scale robot development base of 50,000 square meters in Yichun City, Jiangxi province. Introducing the world’s top advanced production and processing equipment in our factory. We have a technical team and high-quality workers including mechanical, electronic, welding, automatic control, electromechanical integration, and management. We are committed to providing customers with efficient automation welding solutions in order to become a leading enterprise in world-class industrial intelligent equipment.

We have professional production team, production line, experienced technical experts who engaged in this industry for more than 20 years. The main products of our company include capacitor discharge spot welder, pneumatic AC pulse spot welder, three-phase secondary rectifying spot welder, medium frequency inverter spot welder, precision micro spot welder and high degree of automatic welding machine. 1. HWASHI is the leading brand in resistance welding industry in China for 20 years; Factory direct sale, competitive price. 2. Customized Service: We can help to design and develop the welding machine according to your requirement. We are flexible and capable Supplier. 3. Genuine Product with Excellent Quality: 12 months warranty. Our machines are strictly complied with ISO9001:2000 and China Compulsory Certification. Most of our machines enjoy 8-10 years service life. 100% guarantee test before delivery. 4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant. 5. Quick Delivery: Our company provides just-in-time delivery. 6. Prompt Response to Customers: Your satisfaction is the goal we pursue.

Certifications

Quality Control

Cooperrated Customers

FAQ

1. Are you manufacturer or trading company? Answer: We are welding machine manufacturer. We have been in the welding industry for 20 years. We have the rich experienced technical team which can provide you the most professional advice. 2. What information do you need to give me proper recommendation? Answer: In order to recommend you the suitable machine model, please send us the detailed information regarding your product.Like material, thickness, welding position, minimum and maximum size of product, welding requirement, etc. It would be better if you could send us your product drawings. Then our engineer will recommend you the machine according to your welding requirement. 3. Can you provide customized service for our product? Answer: Yes. We will provide you the professional robotic welding system solutions according to your specific product. Only you need to send us your detailed product drawings and welding requirement, then we will come out with the customized technical proposal for you. 4. What’s the warranty period and delivery time? Answer: Warranty period is 12 months. 5. Can you send engineer to our country for setting up the machine? Answer: Yes. We will send engineer to your country to help installation and commissioning, and training. Any problems, we can also provide online service. 6. I want to know the welding quality for our product, what should I do? Answer: You can send your samples to our factory to do test welding. After test welding, we will send the welding video and pictures to you for reference. Also we will send the samples back to you for verification.
